PP 25-1275/2 ROLLING THIN FILM OVEN TEST (RTFOT)
Asphalt Equipment
The Rolling Thin Film Oven Test is used to obtain homogenously aged material by application of heat and air in order to simulate these effect in conventional mixing. This oven is double wall construction with following inside dimension 381 mm high, the door has viewing window made of to sheet heat resistant glass. The oven is vented at the top and bottom, symmetric vent have 15 cm². This oven has an air plenum as described in ASTM D2872 specification. It is also the control panel includes electronic temperature regulator with digital display. The oven has built in 305 mm diameter vertical carousel to hold 8 glass sample, orifice has a 1 mm, diameter and connected to 7.6 mm length cooper. Over heat protection fix in instrument.
- Dimensions (l x w x h)
- 74.5 x 86.4 x 58.4 cm
- Gross Weight
- 99 kg
Consists Of:
PP 25-1275/2-1 Vertical Revolving Shelf Oven
Variable temperature oven fan type up to 200 ± 0.1°C 220 V-AC, 1400 watt, 1 phase, cast aluminum rotating shelf, at 15 rpm.
1 set
PP 25-1275/2-2 Sample Container
Glass Sample Container
8 pc
